Inks tested for every application
Photo source
www.tecglass.es
Designed in the Group’s labs, ceramic inks for digital printing on glass is one of the areas in which Tecglass is invested with ongoing research and innovation.

This means the product range is constantly evolving and always complete in terms of special effects and hues and compatible with the most innovative kinds of glass.

High resistance to climatic stressors and humidity, excellent duration of chromatic effects over time, superior resistance to abrasion in high traffic areas and ideal adaptability to the most advanced glass coatings are just some of the features of Tecglass inks, demonstrated by exceptional results in all the tests.

The advantages of our inks:

- The most extensive range of colors available
The entire range of RAL, Pantone, NCS and many other already-formulated colors are always available, as well as unique colors that no one else can guarantee: like gold, platinum, magenta, subtle shadings and all kinds of luminous effects. Every day the Tecglass labs develop new special colors, upon request, for the most sophisticated and imaginative projects.

- Special effects for innovative projects
Metallic and anti-skid effects, conductive inks and inks integrated with nano-particles for special properties to lend unique effects to the glass.

- Adaptability to all types of glass
Tecglass inks are developed exclusively and custom-designed for use on glass, based on the needs of our clients. No matter what kind of glass you have and whatever your application, we always have the right ink for you.

- Durability and safety for automotive glass
Special formulations for this kind of application are capable of flawlessly meeting the requirements of auto manufacturers.

Tests:

- CLASS A2
Resistance to alkali attack according ISO 695-1991 in accordance with EN 1096-2 by Stazione Sperimentale del Vetro.
- NO CITRIC ACID ATTACK
Resistance to attack of citric acid according to ISO 28706-1:2008 by Stazione Sperimentale del Vetro.
- NO SULFURIC ACID ATTACK VISIBLE THROUGH THE GLASS
Resistance to attack of sulfuric acid according to ISO 28706-1:2008 by Stazione Sperimentale del Vetro.
- NO WATER CONDENSATION ATTACK
Water condensation test UNI 1036-1:2007 resistance to humidity and corrosion.
- CLASS 4 (SUITABLE FOR HIGHT TRAFFIC FLOORS)
Determination of resistance to surface abrasion according UNE-EN ISO 10545-7:1999
- CLASS 3 (69 USRV)
Determination of resistance slip / skid of a surface, pendulum test, according UNE-ENV 12633:2003
- NO COLOR CHANGE AFTER WEATHERING TEST GREATER THAN DELTA E 1.5
Weathering test according to ISO 16474-2:2013, method A cycle 1.1000 hours irradiance of 60w/m2 between 300nm and 400nm with rain simulation by spraying. Test made at the Fraunhofer ISC.
- VERY HIGH SLOPE ANGLE, ABOVE 35°
Slip resistance according to DIN51130 (inclined plane wearing shoes) R-13
