Press Glass Expands Acoustic Glazed Units

Press Glass Expands Acoustic Glazed Units
Photo source
www.pressglass.com
Now PRESS GLASS can provide their customers with as much as 114 various acoustic glazed units.

4 new products have been added to our offer of acoustic glazed units and now we can provide our customers with as much as 114 various acoustic glazed units with Rw coefficient in the range of 31-52 decibels (dB).

Our offer now covers the following glazed units with the Rw index of 44, 47 and 48 dB:



No. Structure [mm] Rw [dB] C [dB] Ctr [dB]
1 12,8T (VSG 66.2T)/16Ar/4/16Ar/6T 44 -2 -6
2 12,8T (VSG 66.2T)/16Ar/4/16Ar/9,5T (VSG 44.4T) 47 -1 -4
3 13,5T (VSG 66.4T) Acoustic/14Ar/12,8T (VSG 66.2T) Acoustic 48 -2 -6
4 12,8T (VSG 66.2T)/16Ar/4/16Ar/27,8T P8B 48 -1 -3



T –  Thermofloat (glass with thermal protection coating)
Ar – Argon – noble gas
VSG – laminated safety glass
P8B – layered laminated (anti-burglary) glass grade according to EN 356

The presented results of tests for new acoustic glazed  units are confirmed with certificates, mandatory and recognised on the European and American market.

The range of PRESS GLASS glazed units now includes a new triple-glazed acoustic glazed  unit with the following structure: 12,8T (VSG 66.2T)/16Ar/4/16Ar/27,8T P8B, which has been tested for acoustic insulation.

The P8B symbol means that a layered laminated anti-burglary glass according to EN 356 was used in the glazed unit. As Tomasz Ślusarek, Senior Quality Specialist in PRESS GLASS, explains the acoustic insulation tests performed on the glass respond to the individual and clearly identified needs of our Customers.

“Our Partners make glazing in different building structures and that is why PRESS GLASS offers such a wide range of acoustic glazed units. We support our Customers and deliver products which live up to their expectations – products whose quality is confirmed by relevant certificates”, explains Tomasz Ślusarek.

Detailed data concerning different types of acoustic glazed units can be checked using our glazed units configurator. A full list of acoustic glazed units is available in the free PRESS GLASS MOBILE application (for iOS and Android).

114 acoustic glazed units in PRESS GLASS' offer

Acoustic glazed units configurator - More
