Date: 12 September 2018

The new innovation by tremco illbruck, being shown at glasstec, integrates high technical performance, flexibility and a safe production process, as well as incorporating environmental and health requirements.

The tremco illbruck booth is located in Hall 17 / C09.

tremco illbruck has taken a holistic approach in developing the new JS910 hybrid sealant for insulating glass units. The new secondary sealant is user and process-friendly, whilst at the same time being compatible with workplace safety and environmental requirements.

The new technology not only optimises the features of the insulating glass and offers practical benefits in the production process, it also dispenses with substances which are hazardous to people or the environment.

glasstec 2018: Redefined hybrid technology for secondary sealant | tremco illbruck



Water-based and free from hazardous substances

In technical terms, JS910 is an innovative polymer which integrates the organic chemistry of carbon with the inorganic chemistry of silicon. The result is a product which combines the key application and performance benefits of silicon, polyurethane and polysulphide.

In achieving this, JS910 also dispenses with the hazardous substances used in existing technologies (such as isocynate, chlorinated paraffins, heavy metals etc.). Instead, JS910 is water-based and therefore requires no hazard pictograms whatsoever.



Flexible curing in all circumstances

In this case, the advance in the production process for manufacturing insulating glass is primarily an advance in the curing process. JS910 A is a one component product with a booster component B. It is ideally used in a standard 10:1 (100:10) volume mixing ratio. However, the mixing tolerance is exponentially higher.

The curing process of all the established 2K sealants is affected by fluctuations in dosage, however JS910 also cures completely without the B component. This means that curing will always takes place, even if an incorrect mixing ratio is used, and there will be no residual soft spots in the edge seal.

Using a standard mixing ratio of 100:10, the curing will occur more quickly than with PU or PS, but with analogue Shore A hardening. Consequently, mechanical strength is achieved quickly, at the same time as long-term flexibility of the edge seal. The completed insulating glass units can therefore be transported quickly, whilst also being durable. The additional benefits of JS910:

  • Reduced contamination of the mixer – lower set up and cleaning times and fewer exchanges of parts
  • Can be disposed of as residual waste – reduced waste disposal costs for rinsing material and end product
  • No risk to employees working on the equipment – improved working conditions and minimised health risk
  • Guaranteed availability of raw materials – the components of JS910 will be available long-term.



Support staff present during changeover

The changeover of the manufacturing process to JS910 requires no more extra effort or expense than a change between PU and PS, for example. Parts which wear, such as seals and hoses, need to be replaced (in part) and the production facility washed down carefully.

tremco illbruck technical support is available to assist with any stage of the process. Experts will support the start-up and fine adjustment of the machines, working together with the equipment manufacturer’s engineers, where necessary.



Comprehensive testing and documentation

JS910 can be used with all established spacer systems – rigid and flexible, metal and warm edge. The wide adhesion spectrum allows it to be used with all commercially available types of glass.

tremco illbruck tests the application of products and their compatibility with other products using the DI-01/1 and VE-05/1 ift guidelines and also in accordance with DIN 18545 and other standards, as required. Due to the absence of aggressive substances in JS910, a higher level of compatibility can generally be expected.

However, in any case, the usual individual testing is still required. The manufacturer will document all product combinations which have already been tested and make the test results available, as required. Where necessary, further testing will be carried out.

Apart from the obligatory system testing carried out in accordance with EN1279, JS910 has already been independently tested by CEKAL and the respective production facilities audited. tremco illbruck has supplemented the climatic chamber system checks specified by EN and CEKAL with additional internal long-term testing.

The results do not show any negative deviation compared to existing sealant technologies. As regards UV resistance, a significant improvement in durability has been determined.
